Figure 5.
STM32H573I-DK PCB layout: bottom side
DT71725V1
ARDUINO
®
connector (CN13)
ARDUINO
®
connector (CN15)
M
IP
I1
0
c
on
n
ec
to
r
(
CN
12
)
ST
-LINK MCU
(U22)
Audio jack
connector (CN9)
Audio codec
(U25)
MEMS digital
microphone (U20)
MIPI20 TRACE
connector (CN18)
ARDUINO
®
connector (CN14)
ARDUINO
®
connector (CN16)
Octo-SPI NOR
flash memory
(U29)
STM32
microcontroller
(U28)
I
DD
m
e
as
ur
e
me
nt
(
JP
6)
7.2
Mechanical dimensions
Figure 6.
STM32H573I-DK mechanical dimensions (top, in millimeters)
DT71726V1
105.00
78.00
UM3143
Mechanical dimensions
UM3143
-
Rev 1
page 10/53
9
