1 Features
• STM32H573IIK3Q microcontroller based on the Arm
®
Cortex
®
‑M33 core with Arm
®
TrustZone
®
, featuring
2 Mbytes of flash memory, 640 Kbytes of SRAM, and cryptography in a UFBGA176 package SMPS option
• 1.54" TFT 240 × 240 pixels color LCD with LED backlight and touch panel
• User USB with USB 2.0 full-speed interface, Sink/Source up to 15 W (5 V / 3 A)
• Ethernet 10/100 Mbit/s, compliant with IEEE-802.3-2002
• SAI audio codec
• One ST-MEMS digital microphone
• 512-Mbit Octo‑SPI NOR flash memory
• Fan-out daughterboard
•
Wi‑Fi
®
module (802.11 b/g/n compliant)
• Four user LEDs
• User and reset push-buttons
• Board connectors:
–
ST-LINK USB Type-C
®
–
User USB Type-C
®
– Ethernet RJ45
– Stereo headset jack including analog microphone input
– microSD
™
card
– Tag‑Connect
™
10-pin footprint
– Arm
®
Cortex
®
10-pin 1.27 mm pitch debug connector (SWD/JTAG)
– Arm
®
Cortex
®
MIPI20 connector (SWD/JTAG/trace)
– ARDUINO
®
Uno V3 expansion
– STMod+ expansion
– Pmod
™
Type-2A and Type-4A expansion
– Audio MEMS daughterboard expansion
• Flexible power-supply options: ST-LINK USB V
BUS
, USB connector, or external sources
• On-board STLINK-V3EC debugger/programmer with USB re-enumeration capability: mass storage, Virtual
COM port, and debug port
• Comprehensive free software libraries and examples available with the STM32CubeH5 MCU Package
• Support of a wide choice of Integrated Development Environments (IDEs) including IAR Embedded
Workbench
®
, MDK-ARM, and STM32CubeIDE
Note: Arm and TrustZone are registered trademarks of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
