16 STM32H573I-DK I/O assignment
Table 32. STM32H573I-DK I/O assignment
Pin number GPIO port Signal or label Comment
P2 PA0 ARD_A2 ADC12_INP0
L3 PA1 RMII_REF_CLK -
M3 PA2 RMII_MDIO -
N5 PA3 ARD_D10 TIM2_CH4, SPI2_NSS
M5 PA4 ARD_A1 ADC12_INP18
R3 PA5 ARD_A3 ACD1_INP19
P5 PA6 ARD_A4 ACD12_INP3
R4 PA7 RMII_CRS_DV -
F15 PA8 ARD_D9 TIM1_CH1
E15 PA9 USART1_TX -
E14 PA10 USART1_RX -
D15 PA11 USB_FS_N -
C15 PA12 USB_FS_P -
E13 PA13 JTMS -
B13 PA14 JTCK -
C13 PA15 JTDI -
R5 PB0 ARD_A0 ADC1_INP9
N6 PB1 OSCSPI1_IO0 -
P6 PB2 OCSPI1_DQS -
B7 PB3 JTDO/TRACESWO -
B6 PB4 NJTRST -
C6 PB5 ARD_D3 TIM3_CH2
C7 PB6 I2C1_SCL -
A6 PB7 I2C1_SDA -
B5 PB8 I2C4_SCL -
A4 PB9 I2C4_SDA -
M10 PB10 ARD_D1 USART3_TX
N12 PB11 ARD_D0 USART3_RX
L12 PB12 STMOD#18 IO
R15 PB13 UCPD_CC1 -
N15 PB14 UCPD_CC2 -
M14 PB15 ARD_D11 SPI2_MOSI, TIM12_CH2
L1 PC0 OCSPI1_IO7 -
L2 PC1 RMII_MDC -
K4 PC2 OCSPI1_IO2 -
N3 PC3 PDM_SAI1_SD3 -
N4 PC4 RMII_RXD0 -
P4 PC5 RMII_RXD1 -
UM3143
STM32H573I-DK I/O assignment
UM3143 - Rev 1
page 39/53
