Pin number GPIO port Signal or label Comment

G14 PC6 LCD_PWR_ON -

G13 PC7 LCD_NE1_CS -

F14 PC8 SDIO1_D0 -

F13 PC9 SDIO1_D1 -

D12 PC10 SDIO1_D2 -

C12 PC11 SDIO1_D3 -

C11 PC12 SDIO1_CK -

E3 PC13 WAKEUP -

D2 PC14-OSC32_IN OSC32_IN -

D1 PC15-OSC32_OUT OSC32_OUT -

B12 PD0 LCD_D2 -

A13 PD1 LCD_D3 -

C10 PD2 SDIO1_CMD -

A12 PD3 LCD_TE -

B11 PD4 LCD_NOE -

A11 PD5 LCD_NWE -

B10 PD6 PDM_SAI1_SD1 -

A10 PD7 NC -

M15 PD8 LCD_D13 -

L13 PD9 LCD_D14 -

K12 PD10 LCD_D15 -

L14 PD11 PDM_SAI1_CK1 -

K14 PD12 OCSPI1_IO1 -

L15 PD13 OCSPI1_IO3 -

K13 PD14 LCD_D0 -

J13 PD15 LCD_D1 -

C5 PE0 DETECTn -

B4 PE1 MEMS_LED -

D4 PE2 TRACECLK -

B2 PE3 TRACED0 -

C3 PE4 PDM_SAI1_SD2 -

D3 PE5 TRACED2 -

C2 PE6 TRACED3 -

R9 PE7 LCD_D4 -

P9 PE8 LCD_D5 -

N9 PE9 LCD_D6 -

R10 PE10 LCD_D7 -

P10 PE11 LCD_D8 -

R11 PE12 LCD_D9 -

P11 PE13 LCD_D10 -

N10 PE14 LCD_D11 -

UM3143

STM32H573I-DK I/O assignment

UM3143 - Rev 1

page 40/53
