Pin number GPIO port Signal or label Comment
N11 PE15 LCD_D12 -
F2 PF0 LCD_A0_RS -
F1 PF1 USER_LED3 -
G3 PF2 NC -
G2 PF3 STMOD#17 IO
G1 PF4 USER_LED4 -
H3 PF5 NC -
H1 PF6 STMOD#1 SPI5_NSS / USART7_RX
K2 PF7 STMOD#3 SPI5_SCK / UART7_TX
H2 PF8 STMOD#4 SPI5_MISO / UART7_RTS
J3 PF9 STMOD#2 SPI5_MOSI / UART7_CTS
J4 PF10 OCSPI1_CLK -
R6 PF11 STMOD#13-ADC ADC1_INP2
N7 PF12 ARD_A5 ADC1_INP6
P7 PF13 IBUS_SENSE -
R7 PF14 VBUS_SENSE -
N8 PF15 NC -
R8 PG0 UCPD_PWR -
P8 PG1 UCPD_FLT -
K15 PG2 NC -
H14 PG3 LCD_CTP_RST -
J15 PG4 ARD_D4 IO
H15 PG5 ARD_D7 IO
J14 PG6 OCSPI1_NCS -
H13 PG7 LCD_CTP_INT -
G15 PG8 ARD_D8 IO
B9 PG9 OCSPI1_IO6 -
A9 PG10 SAI2_SD_B -
C9 PG11 RMII_TX_EN -
B8 PG12 RMII_TXD1 -
C8 PG13 RMII_TXD0 -
A8 PG14 TRACED1 -
A7 PG15 ARD_D2 IO
J1 PH0 OSC_25M -
J2 PH1 NC -
R2 PH2 OCSPI1_IO4 -
P3 PH3 OCSPI1_IO5 -
R1 PH4 STMOD#19 IO
P1 PH5 STMOD#20 IO
P13 PH6 STMOD#12-RST -
P14 PH7 STMOD#9-MISOs SPI5_MISO
UM3143
STM32H573I-DK I/O assignment
UM3143 - Rev 1
page 41/53
