Supplying the board by the user USB T
ype-C
®
connector
The STM32H573I-DK can be supplied from the user USB T
ype-C
®
connector (CN17).
In this case, the 5 V power source selector (JP4) must be placed on pin 3-4 (“USB-PD” on the silkscreen).
Figure 1
1.
JP4 set on the USB_PD pin
T
able 9.
External power source: 5V_USB_CHGR (5 V)
Input power name
Connector
V
oltage range
Max. current
5V_UCPD
CN17
5 V
3
A
UM3143
Supplying the board by the user USB T
ype-C® connector
UM3143
-
Rev 1
page 18/53
17
19
