Pin number
GPIO port
Signal or label
Comment
N13
PH8
STMOD#8-MOSIs
SPI5_MOSI
M12
PH9
STMOD#1
1-INT
-
N14
PH10
ARD_D6
TIM5_CH1
P15
PH1
1
ARD_D5
TIM5_CH2
M13
PH12
STMOD#14-PWM
TIM5_CH3
B15
PH13
LCD_RST
-
D13
PH14
uSD_DETECT
-
C14
PH15
NC
-
K3
NRST
NRST
-
A5
BOOT0
BOOT0
-
A15
PI1
ARD_D13
SPI2_SCK
B14
PI2
ARD_D12
SPI2_MISO
A14
PI3
LCD_BL_CTRL
-
B3
PI4
SAI2_MCLK_A
-
A2
PI5
SAI2_SCK_A
-
C4
PI6
SAI2_SD_A
-
A1
PI7
SAI2_FS_A
-
E2
PI8
USER_LED2
-
E1
PI9
USER_LED1
-
F4
PI10
RMII_RX_ER
-
F3
PI1
1
AUDIO_NRST
-
UM3143
STM32H573I-DK I/O assignment
UM3143
-
Rev 1
page 42/53
