Stryker 3002 - Setup Procedures; Initial Bed Setup and Testing

www.stryker.com 3006 -109-101 REV A 15
Return To Table of Contents
To prevent permanent damage to this unit, the unit must reach room temperature prior to conducting any setup
and/or unit operations.
It is important that the S3™ MedSurg Bed, Model 3002 Patriot™ Series is working properly before it is put into service.
The following list will help ensure that each part of the bed is tested.
WARNING
• The S3™ MedSurg Bed, Model 3002 Patriot™ Series is equipped with a hospital grade plug for protection against
electric shock hazard. It must be plugged directly into a properly grounded three prong receptacle. Grounding
reliability can be achieved only when a hospital grade receptacle is used.
• Use only a Stryker supplied interface cable. Use of any other cable may cause the bed to function improperly
which may result in patient or user injury.
1. Plug the bed into a properly grounded, hospital grade wall receptacle and ensure the LED light at the foot
end of the bed comes on.
2. Plug the optional interface cable into the 37-pin connector under the litter frame at the head end of the bed, into
the “Patient Station”, “Head Wall”, “Docker Station” or equivalent (whichever applies). Test the interface cable to
verify it is functioning properly.
3. Ensure the siderails raise, lower, lock in the up position, lock in the intermediate position when lowered and store
smoothly (page 19).
4. Ensure that all four casters lock when the brake pedal is engaged (page 17).
5. Raise the fowler (head of bed) up to approximately 60
0
. Squeeze the CPR release handle and ensure the back
will drop with minimal effort.
Note
Ensure that the “Brake” LED located on the outside of the head end siderails and on the footboard control panel
blink when the brakes are not engaged.
6. Perform each function on the footboard control panel to ensure that each function is working properly (page 27).
7. Perform each function on both head end siderails to ensure that each is working properly (page 22).
8. Activate the motion stop system to ensure it is functioning properly; press and hold the BED DOWN key. As the
bed lowers, push up on the motion interrupt pan under the bed and ensure the downward motion stops. Release
the pan and allow the downward motion to continue.
Note
The bed’s upward motion or other functions are not disrupted by the motion stop system.
9. If the bed is equipped with the Nurse Call option, verify it is functioning properly prior to patient use.
If any problems are found during bed setup, contact Stryker Technical Support at (800) 327−0770.
Setup Procedures
