Introduction
This manual is designed to assist you with the operations of the S3™ MedSurg Bed, Model 3002 Patriot™ Series. Read
it thoroughly before using the equipment.
INTENDED USE – STRYKER S3™
This device is an AC-powered adjustable hospital bed intended for medical purposes that consists of a bed with a
built-in motor and remote controls that can be operated by the patient to adjust the height and surface contour of the
bed. The device includes movable and latchable siderails.
INTENDED USE – iBED
®
WIRELESS WITH iBED
®
AWARENESS
The intended use for the iBed
®
Wireless (with iBed
®
Awareness) is to assist clinical staff to monitor bed parameters
on specific Stryker beds. The desired bed parameters will be set by clinicians at the bedside. The iBed
®
Wireless
software is intended to be used only with specifically enabled Stryker beds that have been verified and validated with
the iBed
®
Wireless software, and is not intended to provide bed status information for non-Stryker beds. The iBed
®
Wireless software is not intended to communicate any patient status information, nor to permanently store any type
of data. The iBed
®
Wireless with iBed
®
Awareness System is not intended to provide automated treatment decisions
or as a substitute for professional healthcare judgment. The iBed
®
Wireless with iBed
®
Awareness System is not a
replacement or substitute for vital signs monitoring or alert equipment. All patient medical diagnosis and treatment are
to be performed under direct supervision and oversight of an appropriate health care professional.
SPECIFICATIONS
Safe Working Load
Note: Safe Working Load indicates the sum of the
patient, mattress, and accessory weight.
500 lbs 227 kg
Bed Weight 570 lbs 259 kg
Scale System Capacity (optional equip-
ment). Loads weighing up to
500 lbs 227 kg
Scale System Accuracy (optional equipment) ± 2 pounds at 0° - ± 10° Trendelenburg for patients
weighing 100 pounds or less
± 2% of the total patient weight at 0° - ± 10°
Trendelenburg for patients weighing greater than
100 pounds
Overall Length/
Width
Standard Bed Siderails Up 93” x 41-1/2” 236.2 cm x 105.41 cm
Siderails Down 93” x 39-1/2” 236.2 cm x 100.3 cm
Patient Sleep Surface - Standard Bed 84” x 35” 213.4 cm x 88.9 cm
Bed Height to Top of Seat
Litter - 6” Casters
Standard 16” to 30” ±0.5 40.6 cm to 76.2 cm
Litter Platform
to Top of
Siderail
Full Up Head End Siderail 15” 38.1 cm
Full Up Foot End Siderail 15 -1/2” 39.37 cm
Space Between Siderails (Full Up) 2-1/4” 5.72 cm
Knee Gatch Angle 0° to 45°
Fowler Angle 0° to 60°
Trendelenburg/Reverse Trendelenburg +12° to -10° ± 1°
Electrical Requirements - all electrical requirements meet
UL 2601 specifications.
115VAC, 60Hz, 8A
