Setup Procedures
iBED
®
WIRELESS OPTION
In order for your bed to be capable of receiving a wireless connection the iBed Locator needs to be installed on the
wall at the head end of the bed. The iBed Locator communicates with the IR Module installed in your bed. For detailed
instructions on mounting the 5212 iBed Locator refer to the instruction sheet (part number 5212-009-101) packaged
with your optional 5212 iBed Locator Installation kit.
If any problems are found during the iBed Locator Installation, contact Stryker Technical Support at (800) 327−0770.
WARNING
• The iBed Locator must be correctly associated or mapped to the room / location in order to provide accurate
location information. Failure to properly map the iBed Locator to the room / location will yield incorrect remote
information. Additionally, if an iBed Locator is to be moved after it has been installed and mapped, it must be re-
mapped to the new room / location in which it is moved to. iBed Locator re-mapping will also be required if the
room / location information is changed after initial installation.
The wireless connection settings need to be loaded before the device will communicate with the iBed Server application.
Reference the iBed Server Installation and Configuration Manual (5212-009-001).
