Stryker 6390 User Manual

www.stryker.com 6390-009-002 REV D 95
Transfer assembly
Item Number Name
Quantity
E 0004-666-000 Button head cap screw 9
F 0027-778-000
Slic pin
1
G
0038-606-000
Compression wire
3
H 6390-101-018
Foot end fastener assembly (Foot end
fastener assembly on page 96)
1
J 6390-001-021
Transfer trolley lock assembly
(Transfer trolley lock assembly on page
97)
1
K 6390-001-200
Transfer extrusion
1
L 6390-001-201 Roller rail rod 8
M 6390-001-203
Transfer magnet
2
N 6390-001-204
Transfer magnet spacer
1
P 6390-001-205 Magnet mover trigger
1
R 6390-001-207
Transfer back cover
1
T 6390-001-208 Mid position head end cutout cap 2
U 6390-001-213 Inductive charger cover plate
1
V 6390-001-217 Lock latch indicator slide block
1
W 6390-001-230
Transfer lock trigger base
2
Y 6390-001-231
Transfer lock trigger
2
AA 6390-001-233
Transfer lock slide
2
AB 6390-001-240 Magnet mover
1
AC
6390-001-242 Magnet mover glide
1
AD 6390-001-243 Dead stop bumper 2
AE 6390-001-244 Dead stop block, thru hole 2
AF 6390-001-246 Dead stop block, threaded 2
AG
6390-101-260
Transfer lock plate
2
AH 6390-001-261
Transfer lock override slide
2
AJ 6390-001-266
Transfer lock link, short
1
AK 6390-001-267
Transfer lock link, long
1
AL 6390-001-269 Detent spring
1
AM 6390-001-270 Detent roller
1
AN 6390-001-299 Label, chevron
1
AP 0004-585-000 Button head cap screw 2
AR 6506-001-114
Label, warning, crushing of hands
1
AT 6390-001-276
Transfer wear pad
1
