Stryker 6390 User Manual

114 6390-009-002 REV D www.stryker.com
Trolley main frame
Item Number Name
Quantity
A 0001-195-000 Flat head cap screw 3
B 0003-148-000 Hex head cap screw
4
C
0004-874-000
Socket head cap screw
2
D 0004-352-000
Socket head cap screw
6
E 0004-652-000 Button head cap screw 2
F 0004-658-000
Socket head cap screw
3
G
0004-659-000
Socket head cap screw
3
H 0004-660-000
Socket head cap screw
8
J 0004-661-000
Socket head cap screw
5
K 0004-397-000
Socket head cap screw
2
L 0004-665-000 Button head cap screw 2
M 0004-666-000 Button head cap screw 10
N 0005-047-000
Carriage bolt
4
P 0011-436-000 Washer 3
R 0016-014-000 Fiberlock hex nut
5
T 0015-003-000 Hex nut
4
U 6390-001-588
Secondary coil lock
1
V 0018-009-000
Extruded “U” nut
12
W 0023-167-000 Delta screw 3
Y 0023-296-000 Pan head machine screw 6
AA 0023-321-000 Delta screw 3
