Stryker Power-LOAD 6390 Maintenance Manual

A
B
A
FFiigguurree 1133 –– TTrroolllleeyy ttoopp ccoovveerr
2. Using a T25 Torx driver, remove the three screws (C) left side cover (D) (Figure 14).
3. Using a 5/32" hex wrench, remove one hex head screw (E) from the top of the left side cover (D) (Figure 14).
4. Remove the cover. Save the side cover, left and all screws for reinstallation.
5. Repeat steps 2-4 to remove the side cover, right (F) (Figure 14).
EN 36 6390-309-002 Rev AB.0
