FFiigguurree 1122 –– AAttttaacchh tthhee ffoooott eenndd ttrraannssffeerr wweeaarr ppaadd
24.Move the transfer assembly into its mid position (Q) (Figure 13).
Q
FFiigguurree 1133 –– PPoossiittiioonn tthhee ttrraannssffeerr aasssseemmbbllyy
25.Carefully lift the trolley assembly by its arm and wing. Do not lift the trolley by the manual cot release handles. Lift only
where indicated. Installer 1, position hands at R1 and R2. Installer 2, position hands at S1 and S2 (Figure 14).
