IG(H4SO)-2
IGNITION
General Description
1. General Description
A: SPECIFICATIONS
*: Without catalytic converter
**: With catalytic converter
Item Designation
Ignition coil & ignitor
ASSY
Model
1.6 L CM12 — 100C
2.0 L
FH0137
2.5 L
Manufacturer
1.6 L HITACHI
2.0 L
DIAMOND
2.5 L
Primary coil resistance
1.6 L 0.7 Ω±10%
2.0 L
0.73 Ω±10%
2.5 L
Secondary coil resistance
1.6 L 18.0 kΩ±20%
2.0 L
12.8 kΩ±15%
2.5 L
Insulation resistance between primary terminal
and case
More than 100 MΩ
Spark plug
Type and manufacturer
1.6 L
NGK: BKR6E*
CHAMPION: RC8YC4**
NGK: BKR6E-11** (Alternate)
2.0 L NGK: BKR6E*
CHAMPION: RC10YC4**
NGK: BKR5E-11** (Alternate)
2.5 L
Thread size mm 14, P = 1.25
Spark plug gap mm (in)
0.7 — 0.8 (0.028 — 0.031)*
1.0 — 1.1 (0.039 — 0.043)**
