FU(H4SO)-35
FUEL INJECTION (FUEL SYSTEMS)
Idle Air Control Solenoid Valve
11.Idle Air Control Solenoid
Valve
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Disconnect the connector from the idle air con-
trol solenoid valve.
3) Remove the idle air control solenoid valve from
throttle body.
B: INSTALLATION
Install in the reverse order of removal.
NOTE:
• For tightening torque, refer to “COMPONENT”.
<Ref. to FU(H4SO)-3, COMPONENT, General De-
scription.>
• Replace the gasket with a new one.
FU-00009
FU-00298
FU-00299
