SC(H4SO)-2
STARTING/CHARGING SYSTEMS
General Description
1. General Description
A: SPECIFICATIONS
1. NON-TURBO MODEL
*: For Australia and general
Item Designation
Starter
Type Reduction type
Vehicle type MT 1.6 L AT 2.0 L AT, 2.5 L AT
Model M000T30471 M000T30571 M000T20171
Manufacturer Mitsubishi Electric
Voltage and output 12 V — 1.0 kW 12 V — 1.4 kW
Direction of rotation Counterclockwise (when observed from pinion)
Number of pinion teeth 8 9
No-load charac-
teristics
Voltage 11 V
Current 95 A or less 90 A or less
Rotating speed 2,500 rpm or more 2,000 rpm or more
Load character-
istics
Voltage 7.5 V 7.7 V
Current 300 A 400 A
Torque
8.84 N·m (0.90 kgf-m, 6.5 ft-lb) or
more
16.7 N·m (1.70 kgf-m, 12.3 ft-lb) or
more
Rotating speed 870 rpm or more 710 rpm or more
Lock character-
istics
Voltage 4 V 3.5 V
Current 680 A or less 960 A or less
Torque
17 N·m (1.73 kgf-m, 12.5 ft-lb) or
more
31 N·m (3.16 kgf-m, 22.9 ft-lb) or
more
Generator
Type
Rotating-field three-phase, voltage regulator built-in type, with load response
control system
Model A2TB5391, A2TB6291*
Manufacturer Mitsubishi Electric
Voltage and output 12 V — 75 A
Polarity on ground side Negative
Direction of rotation Clockwise (when observed from pulley side)
Armature connection Three-phase Y-type
Output current
1,500 rpm — 30 A or more
2,500 rpm — 64 A or more
5,000 rpm — 76 A or more
Regulated voltage 14.1 — 14.8 V [20°C (68°F)]
Battery
Type and capac-
ity
Europe and
South America
12 V — 48 AH (55D 23L)
1.6 L: 12 V — 48 AH (55D 23L)
2.0 L: 12 V — 52 AH (65D 23L)
2.5 L: 12 V — 52 AH (75D 23L)
Others 12 V — 27 AH (34D 19L)
