FU(H4SO)-50
FUEL INJECTION (FUEL SYSTEMS)
Fuel
20.Fuel
A: OPERATION
1. RELEASING OF FUEL PRESSURE
WARNING:
• Place “NO FIRE” signs near working area.
• Be careful not to spill fuel.
1) Disconnect the connector from fuel pump relay.
2) Start and run the engine until it stalls.
3) After the engine stalls, crank it for 5 more sec-
onds.
4) Turn the ignition switch to OFF.
2. DRAINING FUEL
WARNING:
• Place “NO FIRE” signs near working area.
• Be careful not to spill fuel.
1) Set the vehicle on a lift.
2) Disconnect the ground cable from battery.
3) Open the fuel filler flap lid, and then remove the
fuel filler cap.
4) Lift-up the vehicle.
5) Drain fuel from the fuel tank.
Set a container under the vehicle, and then remove
the drain plug from fuel tank.
6) Tighten the fuel drain plug.
Tightening torque:
26 N·m (2.7 kgf-m, 19.2 ft-lb)
FU-00262
FU-00009
FU-00898
To Next Page
