EN(H4SO)(diag)-34
ENGINE (DIAGNOSTICS)
Subaru Select Monitor
NOTE:
For detailed operation procedure, refer to the SUBARU SELECT MONITOR OPERATION MANUAL.
Crankshaft position sensor signal Crankshaft Position Sig. — OFF
Camshaft position sensor signal Camshaft Position Sig. — OFF
Rear defogger switch signal Rear Defogger SW — OFF (At OFF)
Blower fan switch signal Blower Fan SW — OFF (At OFF)
Light switch signal Light Switch — OFF (At OFF)
Wiper switch signal Wiper Switch — OFF (At OFF)
Air conditioner compressor relay output signal A/C Compressor Signal — OFF
Radiator fan relay 1 signal Radiator Fan Relay #1 — OFF
Radiator fan relay 2 signal Radiator Fan Relay #2 — OFF
Fuel pump relay signal Fuel Pump Relay — ON
Air assisted injector solenoid valve signal Assist Air Sol. Valve — ON or OFF
Engine torque control signal #1 Torque Control Signal #1 — OFF
Engine torque control signal #2 Torque Control Signal #2 — OFF
Engine torque control permission signal
Torque Permission Sig-
nal
— ON or OFF
Remarks Display
Unit
of measure
Note (at idling)
