FU(H4SOw/oOBD)-4
FUEL INJECTION (FUEL SYSTEMS)
General Description
(1) Intake manifold gasket RH (12) Fuel pipe protector LH (22) Plug cord holder RH
(2) Fuel injector pipe (13) Intake air temperature and mani-
fold absolute pressure sensor
(23) Accelerator cable bracket
(3) Fuel injector
(4) O-ring (14) O-ring Tightening torque: N·m (kgf-m, ft-lb)
(5) O-ring (15) Plug cord holder LH T1: 1.5 (0.15, 1.1)
(6) Plug (16) Fuel pipe protector RH T2: 3.4 (0.35, 2.5)
(7) PCV valve (17) Fuel pipe ASSY T3: 6.4 (0.65, 4.7)
(8) Purge control solenoid valve (18) Fuel hose T4: 17 (1.7, 12.5)
(9) Nipple (19) Clip T5: 19 (1.9, 14.0)
(10) Intake manifold (20) Clip T6: 25 (2.5, 18.4)
(11) Intake manifold gasket LH (21) Guide pin
To Next Page
