FU(H4SO)-4
FUEL INJECTION (FUEL SYSTEMS)
General Description
(1) Intake manifold gasket RH (12) Intake manifold gasket LH (23) Accelerator cable bracket
(2) Fuel injector pipe (13) Fuel pipe protector LH (24) EGR valve
(3) Fuel injector (14) Plug cord holder LH
(4) O-ring (15) Fuel pipe protector RH Tightening torque: N·m (kgf-m, ft-lb)
(5) O-ring (16) Fuel pipe ASSY T1: 1.5 (0.15, 1.1)
(6) O-ring (17) Fuel hose T2: 6.4 (0.65, 4.7)
(7) Plug (18) Clip T3: 17(1.7, 12.5)
(8) PCV valve (19) Clip T4: 19 (1.9, 14.0)
(9) Purge control solenoid valve (20) Air assist injector solenoid valve T5: 25 (2.5, 18.4)
(10) Nipple (21) Guide pin
(11) Intake manifold (22) Plug cord holder RH
