EX(H4SOw/oOBD)-3
EXHAUST
General Description
(1) Front exhaust pipe upper cover (15) Muffler (28) Rear catalytic converter upper
cover
(2) Front exhaust pipe lower cover (16) Cushion rubber
(3) Clamp (17) Rear exhaust pipe (29) Rear catalytic converter lower
cover
(4) Front exhaust pipe upper cover LH (18) Lower clamp
(5) Front exhaust pipe lower cover LH (19) Center exhaust pipe upper cover (30) Rear catalytic converter
(6) Front exhaust pipe (20) Center exhaust pipe lower cover
(7) Front exhaust pipe lower cover RH (21) Protector Tightening torque: N·m (kgf-m, ft-lb)
(8) Front exhaust pipe upper cover
RH
(22) Gasket T1: 8 (0.8, 5.9)
(23) Oxygen sensor T2: 13 (1.3, 9.6)
(9) Gasket (24) Front catalytic converter T3: 18 (1.8, 13.3)
(10) Spring (25) Center exhaust pipe T4: 21 (2.1, 15.5)
(11) Chamber (26) Front catalytic converter lower
cover
T5: 30 (3.1, 22.1)
(12) Gasket T6: 35 (3.6, 25.8)
(13) Gasket (27) Front catalytic converter upper
cover
T7: 48 (4.9, 35.4)
(14) Self-locking nut
To Next Page
