ME(H4SO)-6
MECHANICAL
General Description
Crankshaft
Bend limit 0.035 mm (0.0014 in)
Crank pin and
crank journal
Out-of-roundness 0.020 mm (0.0008 in) or less
Grinding limit 0.250 mm (0.0098 in)
Crank pin outer
diameter
1.6 L
STD 47.984 — 48.000 mm (1.8891 — 1.8898 in)
0.03 mm (0.0012 in)
US
47.954 — 47.970 mm (1.8879 — 1.8886 in)
0.05 mm (0.0020 in)
US
47.934 — 47.950 mm (1.8872 — 1.8878 in)
0.25 mm (0.0098 in)
US
47.734 — 47.750 mm (1.8793 — 1.8799 in)
2.0 L
2.5 L
STD 51.984 — 52.000 mm (2.0466 — 2.0472 in)
0.03 mm (0.0012 in)
US
51.954 — 51.970 mm (2.0454 — 2.0461 in)
0.05 mm (0.0020 in)
US
51.934 — 51.950 mm (2.0446 — 2.0453 in)
0.25 mm (0.0098 in)
US
51.734 — 51.750 mm (2.0368 — 2.0374 in)
Crank journal
outer diameter
#1, #3
STD 59.992 — 60.008 mm (2.3619 — 2.3625 in)
0.03 mm (0.0012 in)
US
59.962 — 59.978 mm (2.3607 — 2.3613 in)
0.05 mm (0.0020 in)
US
59.942 — 59.958 mm (2.3599 — 2.3605 in)
0.25 mm (0.0098 in)
US
59.742 — 59.758 mm (2.3520 — 2.3527 in)
#2, #4, #5
STD 59.992 — 60.008 mm (2.3619 — 2.3625 in)
0.03 mm (0.0012 in)
US
59.962 — 59.978 mm (2.3607 — 2.3613 in)
0.05 mm (0.0020 in)
US
59.942 — 59.958 mm (2.3599 — 2.3605 in)
0.25 mm (0.0098 in)
US
59.742 — 59.758 mm (2.3520 — 2.3527 in)
Thrust clearance
STD 0.030 — 0.115 mm (0.0012 — 0.0045 in)
Limit 0.25 mm (0.0098 in)
Oil clearance
#1
STD 0.010 — 0.030 mm (0.0004 — 0.0012 in)
Limit 0.040 mm (0.0016 in)
#2
STD 0.010 — 0.030 mm (0.0004 — 0.0012 in)
Limit 0.045 mm (0.0018 in)
#3
STD 0.010 — 0.030 mm (0.0004 — 0.0012 in)
Limit 0.040 mm (0.0016 in)
#4
STD 0.010 — 0.030 mm (0.0004 — 0.0012 in)
Limit 0.045 mm (0.0018 in)
#5
STD 0.010 — 0.030 mm (0.0004 — 0.0012 in)
Limit 0.040 mm (0.0016 in)
