SummaCut Series Cutters User’ s Manual
General Information 1-6
To order replacement knives, pens and/or pouncing tools, contact your local
dealer, quoting the part numbers listed in table 1-9.
The SummaCut cutters will only perform according to specifications if a
genuine Summagraphics knife, pen or pouncing tool is installed. Do not
replace the standard knife, pen or pouncing tool with products from other
manufacturers.
1.2.4.INTERFACE
Communication
asynchronous RS-232-C
Serial : I/O Port connector
DB-9P
Mating connector
DB-9S
Byte format
8 data bits, 2 stop bits, no parity
Baud rate
38400, 19200, 9600, 4800, 2400 BPS
TABLE 1-4:
SUMMACUT SERIES INTERFACE SPECIFICATIONS
1.2.5.FIRMWARE
Language
DM/PL, HP-GL (758x emulation), HP-GL/2
Supported character sets
Standard ASCII
Supported fonts
Sans serif (single stroke & medium)
ROM-based plots
Confidence plot, DIN plot
TABLE 1-5:
SUMMACUT SERIES FIRMWARE
