SummaCut Series Cutters User’ s Manual
Operation 2-8
2.2.11. ADDRESSING
The ADDRESSING parameter is used to select the cutter’ s default DM/PL user-
addressable resolution. In HP-GL & HP-GL/2 the addressing is fixed at 0.025
mm.
The default addressing resolution is 0.025 mm (Europe) or 0.001" (US).
The user-addressable resolution can be set to 0.025 mm or 0.001" or 0.1 mm or
0.005".
2.2.12. BAUD RATE
The BAUD RATE parameter is used to set or modify the operating baud rate for
RS-232-C serial communications between your cutter and the host computer.
The default baud rate is 9600 bps.
The baud rate can be set to any of the following values: 2400 bps, 4800 bps,
9600 bps, 19200 and 38400 bps.
NOTE
The baud rate setting of your cutter MUST match the host computer’ s
baud rate setting.
2.2.13. PARITY
The PARITY submenu is used to set or modify the byte format and parity type for
RS-232-C serial communications between your cutter and the host computer.
The default parity setting is bit 8 = 0 (8 data bits, no parity, the 8th bit being a
low bit). The parity can be set to any of the following values:
information Parity setting Remarks
BIT 8 = 0
8 data bits, no parity bit 8 = low (0)
BIT 8 = 1
8 data bits, no parity bit 8 = high (1)
EVEN
7 data bits, 1 parity bit parity bit = even
ODD
7 data bits, 1 parity bit parity bit = odd
NOTE
The parity setting of your cutter MUST match the host computer’ s
parity setting.
