SummaCut Series Cutters User’ s Manual
Interface 4-2
4. To redirect the output to serial port #1, enter the following command at
the system prompt: MODE LPT1:=COM1:.
5. To redirect the output to serial port #2, enter the following command at
the system prompt: MODE LPT1:=COM2:.
6. The computer end of the cable must be plugged into the serial port
defined as COM1 (or COM2). The cutter’ s baud rate must be set to 9600,
with parity NONE and RTS/DTR mode set to TOGGLE.
4.2.1.2. Windows 3.xx.
è To set up your system, proceed as follows:
1. Select “Main group” in the Program Manager. Select “Control Panel’,
then “Ports” and then the port that is connected to the cutter. Press the
“Settings” Button to see the port settings.
2. The default settings of the cutter are as follow:
• Baudrate : 9600 (see 2.2.12.)
• Data Bits : 8
• Parity : none (see 2.2.14.)
• Stop Bits: 2
• Flow Control : Hardware or Xon / Xoff
4.2.1.3. Windows 95
è To set up your system, proceed as follows:
1. Press the “Start” Button and select “Settings”, continued by “Control
Panel”. Press on the “System” icon and select the “Device Manager” tab.
Select the port that is connected to the cutter and click on the properties
button. Select the “Port Settings” tab to set the port settings.
2. Analogous to 4.2.1.2.
