SummaCut Series Cutters User’ s Manual
General Information 1-7
1.2.6. PERFORMANCE
Cutting specifications on 0.05 mm (0.002") wax-backed vinyl, total media
thickness not greater than 0.25 mm (0.010")
Axial speed
50 to 600 mm/s 2 to 24 ips
Default speed
500 mm/s 20 ips
Acceleration
up to 2 G up to 2 G
Addressable resolution
0.025 mm, 0.1 mm 0.001", 0.005"
Default resolution
0.025 mm 0.001"
Mechanical resolution
0.0127 mm 0.0005"
Accuracy
0.2% of move or 0.25
mm, whichever is
greater
*
0.2% of move or 0.010",
whichever is greater
*
Knife pressure
0 to 400 gr. 0 to 400 gr.
Pen pressure
0 to 400 gr 0 to 400 gr.
Pouncing pressure
0 to 400 gr 0 to 400 gr.
*
Excludes differences due to media expansion, stretching, etc.
TABLE 1- 6:
SUMMACUT SERIES PERFORMANCES
1.2.7. CERTIFICATIONS
CE-Certification
FCC Class A
EN50022:1987
EN50082-2:1995
IEC 950 , EN 60950
UL 1950
CSA 950
1.2.8. ENVIRONMENTAL
(cutter without media)
Operating Temperature
15 to 35° C 59 to 95° F
Storage temperature
-30 to 70° C -22 to 158° F
Relative humidity
35 - 85 %, non
condensing
35 - 85 %, non
condensing
TABLE 1-7:
SUMMACUT SERIES ENVIRONMENTAL SPECIFICATIONS
