SummaCut Series Cutters User’ s Manual
Operation 2-4
2.1.5. BOOT KEYS
The SummaCut has some internal boot tests.
To activate these boot tests press, while powering on the unit, the
corresponding key on the control panel until the power LED flashes or
repeated beeps are heard. Then release the key, and the selected test will be
activated.
left key: activates the MENU PLOT. Make sure that an A3 format paper is
laoded and that the pen is installed. The MENU PLOT is a hard copy of the
present cutter configuration, i.e. the items selected in the USER CONFIG
submenus. The plot is organised by menu categories to show the current values
for the various USER CONFIG 1(->4) configurations.
NOTE
It is strongly recommended to produce a MENU PLOT hard copy
each time you alter the cutter configuration. The resulting plot should
be kept with the cutter documentation in order to provide other users
with details of the actual configurations of the unit.
right key : activates the Din Test. Make sure that some media is loaded in
the unit. The DIN CUT also performs an electrical and mechanical test of the
cutter, in order to check the cut quality, but also provides the user with
feedback on knife setting, knife pressure, knife offset and cutting depth.
This cut is always run as a DIN A4 portrait/A-size image, regardless of the actual
size of the media loaded. If the media loaded is smaller than DIN A4/A-size,
part of the outer box will be clipped (not cut). This cut is always executed in the
sequence prescribed by the ISO DIN standard.
