10 Appendix
10.1 Technical Data
Parameters SG110CX SG110CX-20
Input (DC)
Max. PV input voltage 1100 V
(1)
Min.PV input volt
age/Start-up input
voltage
200 V / 250 V
Nominal input voltage 585 V
MPP voltage range 200 V ~ 1000 V
MPP voltage range for
rated power
550 V ~ 850 V
(2)
No. of independent
MPP inputs
9
No. of PV strings per
MPPT
2
Max. PV input current 26 A × 9
Max. DC short-circuit
current
40 A × 9
Output (AC)
AC output power 110 kVA @ 45
℃
/ 100 kVA @ 50
℃
Max. AC output cur
rent
158.8 A
Nominal AC voltage 3 / N /
PE，
400 V
AC voltage range 320 V ~ 460 V
Nominal grid frequen
cy / Grid frequency
range
50 Hz / 45 – 55 Hz
60 Hz / 55 – 65 Hz
Harmonic (THD) < 3 % (at nominal power)
Power factor at nomi
nal power / Adjustable
power factor
>0.99 / 0.8 leading – 0.8 lagging
Feed-in phases / AC
connection
3 / 3–PE
113
