User Manual 5 Electrical Connection
Outer Diameter
D(mm)
Seal
4.5 ~ 6 c
6 ~ 12 a + b
13 ~ 18 b
step 3
Insert the RJ45 connector to the RJ45 jack.
step 4 Pull the cable gently to make sure it is secured, tighten the swivel nut clockwise.
- - End
5.12 Closing the Wiring Compartment
69
