table 5-1 Cable Requirements
Specification
No. Cable Type
Cable Diame
ter(mm)
Cross-sectional Area(m
m
2
)
1 DC cable
PV cable complying
with 1,500V stan
dard
6 ~ 9 4~6
2
Additional
grounding
cable
Outdoor sin
gle-core copper
wire cable
The same as that of the PE wire in the AC ca
ble
L1,L2,L3,(N) wire: 70 ~ 240
Four/Five-core out
door copper or alu
minum cable
(1)(2)
38 ~ 56
PE wire: refer to table 5-2
PE Wire Requirements
L1,L2,L3,(N) wire: 70 ~ 240
3 AC cable
Four single-core
outdoor copper
or aluminum ca
bles
(1)(2)
14 ~ 32
PE wire: refer to table 5-2
PE Wire Requirements
Shielded twisted
pair (terminal block)
0.1 ~ 1.5
4
Communi
cation ca
ble
CAT-5 Ethernet ca
ble (RJ45)
4.5 ~ 18
/
(1) A copper to aluminum adapter terminal is required when an aluminum cable is used. For
details, refer to Aluminum Cable Requirements.
(2) In the case of four single-core cables, a spare AC sealing plate accessory is required as
shown in the following figure. To purchase the AC sealing plate accessory, contact your distrib
utor. If the distributor is unable to provide the AC sealing plate accessory, contact SUNGROW.
figure 5-3 Spare AC Sealing Plate
Inverter for Australia and New Zealand are equipped with the four-core sealing plate
by default.
