Sungrow SG33CX-P2 User Manual

9
2.2 Product Introduction
Model Description
The model description is as follows (take SG30CX-P2 as an example):
Appearance
The following figure shows the appearance of the inverter.
figure 2-2 Appearance
The image shown here is for reference only. The actual product received may differ.
No. Name
Description
1 LED indicator
To indicate the current working state of the inverter.
2
Mounting lugs To hang the inverter onto the mounting-bracket.
3 Handles To move the inverter.
4 Labels
To clearly identify the product, including Warning symbols,
nameplate and QR code.
5
External protec-
tive grounding
terminals
Use to ground the inverter.
6 DC switch
To safely disconnect the DC circuit whenever necessary.
7
Wiring area
DC switches, DC terminals, and communication terminals.
For details, refer to "5.2 Terminal Description"
User Manual 2 Product Description
