81
Classificat-
ion
Parameter
Description
Total Power Factor Power factor of the AC side of the inverter
Gird Frenquency Frequency of the AC side of the inverter
A-B Line Voltage
Line voltageB-C Line Voltage
C-A Line Voltage
Phase A Current
Phase currentPhase B Current
Phase C Current
7.5.3 View Records
Tap Records on the navigation bar to enter the interface showing event records, as shown
in the following figure.
figure 7-7 Records
Fault Alarm Record
Tap Fault Alarm Record to enter the interface, as shown in the following figure.
figure 7-8 Fault Alarm Record
Tap to select a time segment and view corresponding records.
The inverter can record up to 400 latest entries.
Select one of the records in the list and tap the record to view the detailed fault information
as shown in following figure.
User Manual 7 iSolarCloud App
