Step 5 Secure the wires to corresponding terminals. Gently pull the cable backwards to ensure firm
connection.
Observe the terminal layout on the block. Do not connect the phase wires to "PE"
terminal or "N" terminal. Otherwise, unrecoverable damage to the inverter may
follow.
Ensure that the depth L of the socket used is not less than 18 mm.
5 Electrical Connection User Manual
