SunTech ST4940 - Page 41

Doc. Title
ST4940 User Manual
Concerning:
Rev.
Date (dd-mm-yy)
Page of Pages
Features and how to configure ST4940
1.07
0
1-7-2019
41 of 52
RESERVED
MODE
MSG_NUM
RESERVED
RESERVED
MSG_TYPE
Field
Marks
Meaning
HDR
“ST600STT”
Header of Status Report.
DEV_ID
10 char
Device ID.
MODEL
2 char
Device Model (According to table model).
SW_VER
3 char
Number of the released Software Version.
DATE
8 char
GPS date (yyyymmdd).
Year + Month + Day
TIME
8 char.
GPS time (hh:mm:ss).
Hour : Minute : Second
CELL_ID
String
Unique ID of Serving Cell. 8 digits hex
First 8 digits are always 0 when the device connected to 2G network.
MCC
String
Mobile Country Code. 0 ~ 65535
MNC
String
Mobile Network Code. 0 ~ 65535
LAC
String
Location Area Code. 4 digits hex
RX_LVL
String
Signal Strength.
0 ~ 63 in GSM. (RSSI)
0: less than -110 dBm
1: -110 to -019 dBm
… …
62: -49 to -48 dBm
63: greater than -48 dBm
0 ~ 97 in LTE M1 (RSRP)
0: less than -140 dBm
1: -140 to -139 dBm
… …
96: -45 to -44 dBm
97: greater than -44 dBm
