2-2. GPS Specifications
Item
Description
Receiver Type
GPS & Glonass
GPS L1 band(1575.42MHz), Glonass L1 band (1601.71MHz)
Galileo* E1B/L1, Compass* ready
SBAS : WAAS, EGNOS, MASA, GAGAN
Update Rate
1Hz
Accuracy
1)
Position 2.5m CEP
SBAS 2.0m CEP
Acquisition
2)
TCXO
Cold starts 26s
Aided start<1s
Hot start<1s
Sensitivity
3)
Tracking -167dBm
Reacquisition -161dBm
Cold start -149dBm
Back-up Supply
Voltage range : 2.5V to 3.6V
Antenna type
Patch Antenna
Operating Temperature
-20 ~+60℃
*1) All SV @ –130 dBm
*2) It depends on aiding data connection speed and latency
*3) The 3 figures were measured with a good active antenna.
