Protocol
Watchdog
If the PDP or GPRS/HSPA connection keeps going invalid status for a while about 40 minutes
up to 1 hour, then the device will be reboot and recover the data communication in case that
the problem was not caused by the network side.
8. Configuration
Before a device starts being operated, its parameters should be set first. This chapter shows the string to be sent to
device.
There are 3 options of sending string.
Option 1: by using PC.
Option 2: by using GPRS/HSPA network.
Option 3: by messaging via SMS.
In practice, configuration can be made more efficiently with ‘SyncTrak’, i.e. a setting tool provided by Suntech.
Once a device receives a command from the server, it gets back to the server with a relevant response. Device also
changes some parameters (if it is required to do so) or takes an action as instructed below as per the command sent by
the server.
8-1. How to set ‘Network Parameters’
● The table below shows how user can set Network parameters, Server information and PIN Lock code.
HDR
DEV_ID
VER
AUTH
APN
USER_ID
USER_PWD
SEVER_IP
SEVER_PORT
B_SEVER_IP
B_SEVER_PORT
SMS_NO
PIN_NO
CMD_FROM_SERVER
Field
Marks
Value
Meaning
HDR
“ST600NTW”
Command type of Header.
DEV_ID
10 char
Device ID.
VER
“02”
Protocol Version
AUTH
‘0’ /‘1’/’A’
GPRS/HSPA authentication
0 : PAP
1 : CHAP
A : Automatic GPRS/HSPA set.
3 : None
In Automatic case, parameters for APN, USER_ID and
USER_PWD field should remain empty.
