Suzuki GSX1300BK B-King - Front Wheel Assembly Construction

Wheels and Tires: 2D-3
Front Wheel Assembly Construction
B823H12406002
(a)
1
(b)
2
“a”
(a)
1
(c)
3
LH RH
I823H1240061-01
1. Brake disc bolt “a”: Clearance : 100 Nm (10.0 kgf-m, 72.5 lb-ft)
2. Brake caliper mounting bolt : 23 Nm (2.3 kgf-m, 16.5 lb-ft) : Apply grease.
3. Front axle bolt : 39 Nm (3.9 kgf-m, 28.0 lb-ft) : Apply thread lock to the thread part.
