Body Structure: 9E-2
Front Footrest Bracket Construction
B823H19506004
4
2
3
1
(a)
I823H1950002-01
1. Bolt 2. Washer 3. Washer 4. Bushing : 23 Nm (2.3 kgf-m, 16.5 lb-ft)
