AMI Sample Sequencer
Product Description
A-96.250.661 / 120418 11
Step 3 The measurement of sample 1 is finished.
 The solenoid valve [C] is open and the photometer is flushed with
sample stream 2.
 A valid measuring value of sample stream 1 is available.
A
B
C
6-way valve
Constant head
Solenoid valve
D
E
Photometer
Sample inlet constant head
1
123456
34
5
7
6
2
A
B
C
D
E
