AMI Sample Sequencer
Product Description
Step 2  The 6-way valve [A] has switched to sample stream 2
– The -Valid after- time [I] is active. The instrument still
measures channel 1.
– The -Flush time- [G] is active. No valid measuring value is
available for channel 2 yet.
A
B
C
6-way valve
Constant head
Measuring cell
D
E
Sample 1
Mixing zone Sample 1 and 2
1
123456
34
5
7
6
2
B
A
E
D
C
