AMI Sample Sequencer
Installation
Connecting
example with
AMI Silica
A
B
C
Sample inlet 1 to 6
Hose nozzles for waste
connection
Sample outlet of AMI Sample
Sequencer
D
E
F
G
Connection tube
Blind plug
Flow regulating valve
Sample inlet of AMI Silica
Exit Enter
Exit Enter
1 2 3 4
5 6
Level
2L
2L2L
2L
OXYCON ON-LINE SILCA
AMI SILICA REAGENT 1
OXYCON ON-LINE SILCA
AMI SILICA REAGENT 2
OXYCON ON-LINE SILCA
AMI SILICA REAGENT 3
OXYCON ON-LINE SILCA
AMI SILICA REAGENT 4
ABCD
EFG
