AMI Sample Sequencer
Installation
A-96.250.661 / 120418 27
Connecting
example with
AMI Silitrace
A
B
C
Sample inlet 1 to 6
Hose nozzles for waste
connection
Sample outlet of AMI Sample
Sequencer
D
E
F
G
Connection tube
Sample inlet of AMI Silitrace
Flow regulating valve
Blind plug
Exit Enter
1 2 3 4
5 6
2L
2L
2L
OXYCON ON-LINE SILCA
AMI SILICA REAGENT 1
OXYCON ON-LINE SILCA
AMI SILICA REAGENT 2
OXYCON ON-LINE SILCA
AMI SILICA REAGENT 3
OXYCON ON-LINE SILCA
AMI SILICA REAGENT 4
2L
Exit Enter
ABC
D
EF
G
