1. GENERAL INFORMATION
1-9
Specifications
MAKER SANYANG MODEL LH18W-6
Overall Length 2064 mm Front Telescopic Fork
Overall Width 760 mm
Suspension
System
Rear Unit Swing
Overall Height 1165 mm Front 100 / 80 – 16 50P/TL
Dimension
Wheel Base 1385 mm
Tire Specifications
Rear 120 / 80 - 16 60P/TL
Front 53 kg Front Disk (ψ220mm)
Rear 82 kg
Curb Weight
Total 135 kg
Brake System
Rear Drum (ψ130mm)
Passengers/Weight Two /110 kg Max. Speed Above 108 km/hr
Front 75 kg
Performance
Climb Ability Below 28°
Rear 170 kg
Primary
Reduction
Belt
Weight
Total Weight
Total 245 kg
Secondary
Reduction
Gear
Type 4-Stroke Engine Clutch Centrifugal, dry type
Installation and
arrangement
Vertical, below center,
incline 80°
Reduction
Transmission C.V.T.
Fuel Used Unleaded Speedometer 0 ~ 140 km/hr
Cycle/Cooling 4-stroke/water cooled Horn 93~112 dB/A
Bore 61 mm Muffler
Expansion & Pulse
Type
Stroke 58.6 mm
Exhaust Pipe Position and
Direction
Right side, and
Backward
Cylinder
Number/Arrange
ment
Single Cylinder Lubrication System
Forced circulation &
splashing
Displacement 171.2 cc Solid Particulate
Compression Ratio 10.8 : 1 CO Below 5.5 g/ km
Max. HP 11.4kw / 8000rpm
Exhaust
Concentrati
on
HC Below 1.0g/ km
Max. Torque 15.3Nm / 6500rpm E.E.C. ─
Ignition C.D.I. P.C.V. ─
Engine
Starting System Power & Foot
Catalytic reaction control
system
─
