1. GENERAL INFORMATION
1-10
Specifications
MAKER SANYANG MODEL LH12W-6
Overall Length 2064 mm Front Telescopic Fork
Overall Width 706 mm
Suspension System
Rear Unit Swing
Overall Height 1165 mm Front 100 / 80 -16 50P/TL
Dimension
Wheel Base 1385 mm
Tire Specifications
Rear 120 / 80 -16 60P/TL
Front 53 kg Front Disk (ψ220mm)
Rear 82 kg
Curb Weight
Total 135 kg
Brake System
Rear Drum (ψ130mm)
Passengers/ Weight
Two/110 kg Max. Speed Above 100 km/hr
Front 75 kg
Performance
Climb Ability Below 28°
Rear 170 kg
Primary
Reduction
Belt
Weight
Total Weight
Total 245 kg
Secondary
Reduction
Gear
Type 4-Stroke Engine Clutch Centrifugal, dry type
Installation and
arrangement
Vertical, below center,
incline 80°
Reduction
Transmission C.V.T.
Fuel Used Unleaded Speedometer 0 ~ 140 km/hr
Cycle/Cooling 4-Stroke/Water Cooled Horn 93~112 dB/A
Bore 57 mm Muffler
Expansion & Pulse
Type
Stroke 48.8 mm
Exhaust Pipe Position and
Direction
Right side, and
Backward
Cylinder
Number /
Arrangement
Single Cylinder Lubrication System
Forced circulation &
splashing
Displacement 124.5 cc Solid Particulate
Compression Ratio 10.5 : 1 CO Below 5.5g/km
Max. HP 9.2kw / 8500rpm
Exhaust
Concentr
ation
HC Below 1.2 g/km
Max. Torque 10.9Nm / 6500rpm E.E.C. ─
Ignition C.D.I. P.C.V. ─
Engine
Starting System Power & Foot
Catalytic Reaction Control
System
Yes
