2. MAINTENANCE INFORMATION
2-4
Air Cleaner
Air Cleaner Element
Remove 6 screws from the air cleaner cover and
then remove the cover.
Remove 4 screws, and then remove the air
cleaner element.
Caution
The air cleaner element is made of paper so do
not soap it into water or wash it with water.
Spark Plug
Remove central cover.
Remove spark plug cap.
Clean dirt around the spark plug hole.
Remove spark plug.
Measure the spark plug gap.
Spark plug gap：0.8 mm
Carefully bend ground electrode of the plug to
adjust the gap if necessary.
Hold spark plug washer and install the spark plug
by screwing it.
Tighten torque: 1.0~1.2kgf-m
Connect spark plug cap.
Recommended spark plug: CR8E
0.8mm
6 screws
4 screws
Spark plug cap
