Chapter 2 TL1 Command Syntax and Description
Edit Sync (ED-SYNC)
60 TimeProvider TL1 Reference Guide 097-58001-01 Revision E – September 2006
FRMTYPE
(cont’d)
ISOLATED_
1
The framing type generated by the specified output
group is provisioned as an ‘isolated one’ test pattern.
FREEFLT ON Outputs are generated based on system SSM when
the Local Oscillator enters Free-run mode.
SQUELCH
SQUELCH Outputs are squelched (turned off) when the Local
Oscillator enters Free-run mode.
AIS Outputs generate an AIS signal when the Local
Oscillator enters Free-run mode.
HOLDFLT ON Outputs are generated based on system SSM when
the Local Oscillator enters Holdover mode.
ON
SQUELCH Outputs are squelched (turned off) when the Local
Oscillator enters Holdover mode.
AIS Outputs generate an AIS signal when the Local
Oscillator enters Holdover mode.
SSMENA ENABLE ESF or E1 (CCS) outputs generate SSMs. ENABLE
DISABLE ESF or E1 (CCS) outputs do not generate SSMs.
SSMBIT 4 The output SSM is placed in bit position 4. ALL
5 The output SSM is placed in bit position 5.
6 The output SSM is placed in bit position 6.
7 The output SSM is placed in bit position 7.
8 The output SSM is placed in bit position 8.
ALL The output SSM is placed in all bit positions.
<aid> =RTMg[-p]
RTMLBO
Note: For the E1
Retimer, the IPNV
(Invalid
Parameter) DENY
code is returned.
0 Sets the Line Build-out length to 0 to 133 ft 0
1 Sets the Line Build-out length to 133 to 266 ft
2 Sets the Line Build-out length to 266 to 399 ft
3 Sets the Line Build-out length to 399 to 533 ft
4 Sets the Line Build-out length to 533 to 650 ft
FREEFLT CUTTHRU Cut-thru mode is engaged when the Local Oscillator
enters Free-run mode.
RETIME
RETIME Cut-thru mode is not engaged when the Local
Oscillator enters Free-run mode.
Table 2-6. ED-SYNC – Keywords and Values (Continued)
<keyword> <value> Description Default
