GENERAL DESCRIPTION
1.4.2 OUTPUTS
A. MISCELLANEOUS OUTPUTS (15 PIN D CONNECTOR J3)
Table 1-5 lists the various pulse rates, codes, and alarm signals available on this
multipin connector.
Table 1-5
Miscellaneous Outputs (J3)
SIGNAL PIN # SOURCE DRIVE CAPABILITY
1KPPS 1 Generator See Note 1
100PPS 2 Generator See Note 1
10PPS 3 Generator See Note 1
1PPS 4 Generator See Note 1
Carrier 5 Translator See Note 1
Carrier/10 6 Translator See Note 1
Carrier/100 7 Translator See Note 1
Carrier/1K 8 Translator See Note 1
Ground 9 Generator See Note 1
IRIG B DC Code 10 Generator See Note 1
LOS Output* 11 Translator See Note 1
ERR Output 12 Translator See Note 1
13 Not Used
14 Not Used
15 Not Used
Note 1: Outputs will drive a minimum of 4.0V into a 1K resistor to ground, or a
maximum of 0.4V into a 1K resistor to +5V.
All Pulse Rates are 50/50% duty cycle, positive edge on-time.
* Input Threshold (LOSS) is adjustable from 0.5 to 10V P-P with a carrier
frequency of 100Hz - 100kHz.
B. MULTICODE DC CODE OUTPUT (BNC J4)
This output produces a DC level shift serial code that contains the time value
within the TM7000. It is generated by the
Multi-Encoder section. The time code
format is determined by front panel menu selection.
The DC code generated can be IRIG A, IRIG B, IRIG G, NASA 36, XR3, 2137
or AN/GSQ-53 as selected by the Output Code Menu. The time encoded may
come from either the generator or the translator. Codes may be “re/generated”
from the translator at multiple speeds.
Symmetricom, Inc. TM7000 TymMachine TCG/T (Rev D) 1-7
