OPERATION
1PPS Tracking Control Menu
Figure 3.7.5.1
SELECT ON-TIME EDGE 1PPS TRACKING
POSITIVE negative ON off
Selecting the ON-TIME Edge is accomplished by pressing any switch below the desired edge,
either Positive (rising) or Negative (falling). The ON-TIME Edge selected will be shown in
upper case letters on the LCD Display.
1PPS TRACKING may be turned either ON or OFF by depressing the switch below either ON
or OFF. The selected 1PPS TRACKING mode ON or OFF will be displayed in upper case
letters.
Pressing the NEXT or PREV switch changes the LCD Display to the SYNC Select Menu, Figure
3.7.1.2.
3.7.6 GENERATOR SET-UP
Selecting SET-UP from the Select Generator Mode Menu, Figure 3.7.1, leads to the Generator
Set-Up Menu screen shown in Figure 3.7.6.1.
This menu provides a selection of other menus to set-up the Generator and the Computer I/Os.
Generator Setup Menu
Figure 3.7.6.1
Set-up generator.
INPUTS OUTPUTS RS232 488 BUS GPIO
Selecting NEXT will revert the LCD Display to that shown in Versatile Display Function Menu,
Figure 3.7.6.2.
Versatile Display Function Menu
Figure 3.7.6.2
Select VERSATILE DISPLAY function.
GENERATOR TRANSLATOR TAPE SEARCH
Selecting PREV will revert the LCD Display to that shown in Figure 3.7.6.3, the Select
Generator Mode Menu.
Symmetricom, Inc. TM7000 TymMachine TCG/T (Rev D) 3-11
