OPTION DESCRIPTIONS
TM Option 39 Distribution Module, 50Ω Driver Assembly 21006
1.0 INTRODUCTION
This assembly provides three buffered outputs for each input, which must be provided from an
external source. Each output is via a unity gain buffer.
This assembly has three inputs and nine outputs.
1.1 INSTALLATION
This assembly requires 2 vertical slots. The assembly may be installed in any available lower slot.
Remove power from the TM7000. Plug this assembly into the TM7000 being careful to locate the
components on the top side. Be sure input(s) J1, J5, and J9 (if applicable), are connected before
plugging assembly in.. Power up the unit.
1.2 OPERATION
There are no operator adjustments for this option.
1.3 SPECIFICATIONS
Table Three
Input/Output Level/Load/Frequency Detail
Input J1
Level Up to 1.5 VRMs.
Load
Greater than 100KΩ.
Frequency DC to 1.2 MHz.
Outputs J2, J3, and J4
Level Dependent on input.
Load
50Ω or greater.
Frequency Same as J1 Input.
Input J5
Level Up to 1.5 VRMs.
Load
Greater than 100KΩ.
Frequency DC to 1.2 MHz.
Outputs J6, J7, and J8
Level Dependent on input.
Load
50Ω or greater.
Frequency Same as J5 Input.
Input J9
Level Up to 1.5 VRMs
Load
Greater than 100KΩ
Frequency DC to 1.2 MHz
Outputs J10, J11, J12
Level Dependent on Input
Load
50Ω or greater
Frequency Same as J9 Input
Symmetricom, Inc. TM7000 TymMachine TCG/T (Rev D) A-53
